Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester

    Buy cheap Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester from wholesalers

    Buy cheap Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester from wholesalers
    • Buy cheap Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester from wholesalers

    Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester

    Ask Lasest Price
    Brand Name : PEAKMETER
    Model Number : PM18C
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 150,000 Pcs Per Month
    Delivery Time : 5-40 work days
    • Product Details
    • Company Profile

    Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester

    High Precision 6000 Counts Digital Multimeter With Resistance And Capacitance Tester


    English User Manual:https://drive.google.com/open?id=1HcFFSdh220gP1FJrMc0MDpKZyoRXl_5T


    Features of Digital Multimeter


    • AC/DC Voltage, Current, Resistance, Capacitance, Frequency, Duty Ratio Measurement
    • NCV(Non-Contact Voltage), Live line, Transistor, Diode and Continuity Detection as well.
    • PM18C has Data Hold and Temperature Measurement Function.
    • "SEL" key is on the middle, which was designed for some functions selection.
    • Its LCD display has backlight and lighting function, bring convenience to Data reading.
    • Powered by 4 Batteries (not included).

    SpecificationsRangeAccuracy
    DC Voltage600Mv/6V/60V/600V/1000V±(0.5%+3)
    AC Voltage6V/60V±(0.8%+3)
    600V/750V±(1%+10)
    DC Current60µA/60mA/600mA±(0.8%+3)
    20A±(1.2%+3)
    AC Current60mA/600mA±(1.0%+3)
    20A±(1.5%+3)
    Resistance600Ω/6KΩ/60KΩ/600KΩ/6MΩ±(0.8%+3)
    60MΩ±(1.2%+30)
    Capacitance6nF±(4.0%+30)
    60nF/600nF/6µF/60µF/600µF/6mF±(4.0%+3)
    100mF±(5.0%+3)
    Frequency60Hz/600Hz/6KHz/60KHz/600KHz/6MHz/10MHz±(1.0%+3)
    Duty5%~95%±(2.0%+3)
    Temperature-20~1000℃(-4~1832℉)±(1.0%+3)
    hFE0~1000±(1.0%+3)
    Features
    6000 Counts DisplayACV/ACA TRMS
    ACV (bandwidth): 1HzFrequency: 10MHz
    TemperatureDuty: 5%~95%
    Resistance: 60MΩCapacitance: 100mF
    Continuity (Sound and LED Alarm)Diode Test
    hFELive Line Test: Sound And LED Alarm
    Work LightLow Battery Indication
    NCVAuto Power Off
    General
    Power Supply: 4ⅹ1.5V AA batteries
    Net weight: Approx340g
    Gross weight: 584g
    Size: 193mmⅹ90mmⅹ54mm
    Safety Rating: EN61010-1,EN61010-2-033,EN61326,CAT. Ⅲ1000V/CAT.Ⅳ600V

    Description of Digital Multimeter


    PM18C is a high precision and high performance meter with AC/DC voltage, current, resistance, capacitance, frequency, duty ratio measurement. It can also Detection NCV (Non-Contact Voltage), Diode, Live line, Transistor and Continuity. It has a hook at the back of the fuselage, which makes it easy to put on a table and read the values.

    • Allowable max voltage between terminal to be measured and ground: 1000V DC or 750V AC
    • Protection of protection tube: protective tube FF 630Ma/250V and FF 20A/250V
    • Display unit: 6000 counts displayed on LCD screen. Automatically display the symbol for unit in accordance with measurement function position.

    Multifunctional True Rms Digital Multimeter , Capacitance Digital Multi TesterMultifunctional True Rms Digital Multimeter , Capacitance Digital Multi Tester
