    T - MRS AC Digital Clamp Meter Multimeter With NCV Detection And Analogue Bar Graph

    Ask Lasest Price
    Brand Name : PEAKMETER
    Model Number : PM2028B
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T
    Supply Ability : 150,000 Pcs Per Month
    Delivery Time : 5-40 work days
    • Product Details
    • Company Profile

    T - MRS AC Digital Clamp Meter Multimeter With NCV Detection And Analogue Bar Graph

    T - MRS AC Digital Clamp Meter Multimeter With NCV Detection And Analogue Bar Graph


    Features of T-RMS AC Digital Clamp Meter


    • Display: LCD
    • Operating height: Max. 2000m
    • Max. display value: 6000 digit.
    • Over range display: ‘0L’ or ‘-0L’.
    • Automatic shutdown time: 10 minutes
    • Power supply: 1.5V AAA battery × 3
    • Operating temperature: 18℃ ~ 28℃.
    • Storage temperature: -10℃ ~ 50℃.
    • Overload protection throughout the range.
    • Battery under-voltage indication: LCD display symbol
    • Temperature coefficient: Less than 0.1×accuracy/℃.
    • Unit display: Function and electricity quantity unit display.
    • Polarity indication: Automatic indication, and ‘-’ indicates negative.
    • Sampling time: About 3 times/second.,bargraph 10 times/second
    • Max. voltage between measurement terminal and ground: 1000V DC or 1000V AC

    SpecificationsRangeAccuracy
    DC Voltage6V/60V/600V/1000V±(1.0%+3)
    AC Voltage6V/60V/600V/1000V±(1.2%+3)
    AC Current60A/600A/1000A±(3.0%+5)
    Resistance600Ω/6kΩ/60kΩ/600kΩ/6MΩ±(1.0%+3)
    60MΩ±(1.2%+30)
    Frequency100Hz/1000Hz/10kHz±(1.0%+5)
    10%~99%±(3.0%+2)
    Capacitance60nF/600nF/6uF/60uF/600uF/6mF/60mF±(4.0%+3)
    Temperature-20℃~1000℃±(2.0%+2)
    -4℉~1832℉±(2.0%+2)
    LowZDCV 1000V±(1.0%+10)
    ACV 1000V±(2.0%+20)
    Features
    Display6000 counts
    Analogue Bar Graph
    Auto and Manual Range
    True RMS
    Data Hold
    Work Light
    NCV
    Relative Measurement
    Continuity
    Back Light
    VFD
    General
    Power Supply3*1.5V AAA Batteries
    Net weight314g (batteries are not included)
    Gross weight612g
    Size247mm*84mm*40mm
    Jaw SizeØ35mm
    Safety RatingEN61010-1, EN61010-2-033, EN61326, CAT. Ⅲ 600V

    Product Description of T-RMS AC Digital Clamp Meter


    PM2028B is an auto and manual range True RMS digital multimeter. This meter has analogue bar graph and digital display. It can be used to measure AC&DC voltage, AC current, resistance, frequency, capacitance, temperature, etc. It also has functions of data hold, backlight, NCV, VFD, etc.


    • Instrument complies with safety requirements on electronic measuring instrument of EN-61010-1, EN-61010-2-030, level Ⅱ pollution.
    • If there is no operation within about 15 minutes after start, instrument will enter standby state, and shut down to save energy.

    Detailed Images of T-RMS AC Digital Clamp Meter

    T - MRS AC Digital Clamp Meter Multimeter With NCV Detection And Analogue Bar GraphT - MRS AC Digital Clamp Meter Multimeter With NCV Detection And Analogue Bar Graph
